Bobrick Angle Frame Tilt Mirror 18x30
Bobrick Angle Frame Tilt Mirror, series B-294 18x30 two position tilt mirror. This mirror is Ada approved for commercial restrooms. The outside channel is 3/4"x3/4" and is type 304 stainless steel frame. This mirror has a 7" from top wall and the bottom is mounted to wall. Standard 1/4" plate glass is used.
B294-18x30 -
Stainless Steel Fixed Tilt ADA Mirrors
Introducing American Specialties Fixed Ada Tilt Mirrors. Constructed of plate glass and type 304 stainless steel. Frames are roll formed to make the 1/2” x 1/2” x 1/2” channel, the corners are then mitered and secured with stainless steel rivets, with a #4 satin finish. 15 Year warranty against silver spoilage. The mirror taper from 4" at the top to 1" at the bottom. 4 keyhole slots in back of mirror unit connect to the screws on the wall. Also known as 0535 series mirrors.
9A53 -
Desk Top Plexiglass Brackets
Brackets designed to mount plexiglass/acrylic sheets to desk top or work surface when creating separation/barrier. Brackets are adjustable for thickness from 1/8" to 3/8". It is recommended for use of 1/4" Thick material. Sold as a Pair. Made of Aluminum Alloy. Screws and inserts included. Uses a 5mm/3/16" Allen Key(Not Included) to install screws These are available in either Silver or Black Finish. Silver Finish are readily available while Black Finish may have an extended leadtime depending on quantities being ordered.
Measurements
Height: 2-1/2"
Width:1-3/4"
Depth: 5/8"
Weight:About .6lb
PRM-DTB -
Stainless Steel Adjustable Tilt ADA Mirrors
Introducing American Specialties Adjustable Ada tilt mirrors. Offers visibility for wheelchair users or returns to upright position. 18 gauge stainless steel frame with plate glass. Tilts full 6 degrees. 15 Year warranty against silver spoilage. Frames are roll formed to make the 1/2” x 1/2” x 1/2” channel, the corners are then mitered and secured with stainless steel rivets, with a #4 satin finish. Stainless steel hinge pivot brackets and hinge attached mirror to wall. Also known as 0600 series mirrors.
9A600 -
Dual Desk Mount Plexiglass Brackets
Brackets designed to mount plexiglass/acrylic sheets to desk surface edge when creating separation/barrier. Brackets are adjustable for thickness from 1/8" to 3/8". It is recommended for use of 1/4" Thick material. Sold as a Pair. Made of Aluminum Alloy. Screws and inserts included. Uses a 5mm/3/16" Allen Key(Not Included) to install screws These are available in either Silver or Black Finish. Silver Finish are readily available while Black Finish may have an extended leadtime depending on quantities being ordered.
Measurements
Height: 2-1/2"
Width: 1-3/4"
Depth: 5/8"
Weight:About 1.3lb
Top to Bottom: 3-5/8"
Plate Width: 1-3/4"
Plate Length: 5-3/4"
Plate Height: 3/16"
Gap/Spacing: 1"
PRM-DDB -
-
Bobrick Fixed Position Tilt Mirror
Bobrick fixed position tilt mirrors known as B-293 series. These mirrors are ADA approved and are required for commercial restrooms that provide handicap accessibility. The frame is type 304 stainless steel with beveled edges of the frame hug the mirror. This provides a gapless fit for improved appearance and safety when cleaning. The product is a plate glass. The mirror extends 4" from the wall at the top and tapers down to 1" at the bottom.
B293 -
Ampco Toilet Partition Slide Bolt Latch
The Ampco Toilet Partition Slide Bolt Latch is constructed of Zamac die cast metal and then chrome plated. Latch base is 4" high with 2-3/4" hole spacing. Latch bolt is 3-3/16" long by 3/4" wide by 3/16" thick. The latch bolt clearance is 9/16" from the back of the base to the under side of the latch bolt and projects out 15/16". The latch projects out 1-9/16" from the face of the door when installed. Also known as a Bathroom Stall Surface Mounted Slide Bolt Latch. Manufacture part # 5020. Shipped with mounting screws.
9CP100. -
Toilet Partition Slide Bolt Latch SS
The Toilet Partition Slide Bolt Latch is constructed of Cast Stainless Steel. The latch base is 4" high with 2-3/4" hole spacing. Latch bolt is 3-3/16" long by 3/4" wide by 3/16" thick. The latch bolt clearance is 9/16" from the back of the base to the under side of the latch bolt and projects out 15/16". The latch projects out 1-9/16" from the face of the door when installed. Also known as a Bathroom Stall Surface Mounted Slide Bolt Latch and Toilet Partition Locks. Manufacture part # 5023. Shipped with mounting security screws. Also known as 9F0302SS.
This latch is the same as our 9F0302 (5020), but is made of cast stainless steel, which is much more durable and heavy duty.
9A5023 -
ASI Matte Black Double Roll Toilet Tissue Holder
ASI Matte Black double roll toilet tissue holder is a surface mounted unit. Heavey gauge concealed mounting brackets allow this holder to support 2 standard rolls of toilet paper and comes with chrome rollers. The product is stainless steel with a matt black powder coated finish. With a matte black finish this product offers a more sophisticated and bold look while being aesthetically appealing to the eye.
B10-7305-2-41 -
ASI Matte Black Single Roll Toilet Tissue Holder
ASI Matte Black single roll toilet tissue holder is a surface mounted unit. Heavey gauge concealed mounting brackets allow this holder to support a standard rolls of toilet paper and comes with chrome rollers. The product is stainless steel with a matte black powder coated finish. With a matte black finish this product offers a more sophisticated and bold look while being aesthetically appealing to the eye.
B10-7305-41 -
Hiny Hider Aluminum Slide Bolt Latch 3-1/2" Screws
The Hiny Hider Aluminum Slide Bolt Latch 3-1/2" Screws is usually used on Solid Plastic (HDPE) Toilet Partitions. Base is 4-1/2" tall by 2" wide by 1/8" thick. Latch bolt is 3-1/8" long by 1" wide by 1/4" thick, and has a 1" throw. The latch bolt is 9/16" from the bottom of the base to the under side of the latch bolt. Also known as a Bathroom Stall Aluminum Slide Bolt Latch and Toilet Partition Locks. Clear anodized aluminum construction. The manufacture part #'s are 4988, 650-4051, 650-8543 and HLSLA. This latch ships with the mounting screws.
9HLSLA -
Hadrian Toilet Partition Slide Bolt Latch
The Hadrian Toilet Partition Slide Bolt Latch is constructed of Zamac die cast metal that is chrome plated and polished. Latch base is 4" high with 2-3/4" hole spacing. Latch bolt is 3-3/16" long by 3/4" wide by 3/16" thick. The latch bolt clearance is 9/16" from the back of the base to the under side of the latch bolt and projects out 15/16". The latch projects out 1-9/16" from the face of the door when installed. Also known as a Bathroom Stall Surface Mounted Slide Bolt Latch. Manufacture part # 5020. Shipped with mounting screws.
9HH125 -
Flush Metal Partition Slide Bolt Latch
The Flush Metal Partition Slide Bolt Latch is constructed of Zamac die cast metal that is chrome plated and polished. Latch base is 4" high with 2-3/4" hole spacing. Latch bolt is 3-3/16" long by 3/4" wide by 3/16" thick. The latch bolt clearance is 9/16" from the back of the base to the under side of the latch bolt and projects out 15/16". The latch projects out 1-9/16" from the face of the door when installed. Also known as a Bathroom Stall Surface Mounted Slide Bolt Latch. Manufacture part # 5020. Shipped with mounting screws.
9FL800 -
ASI Recessed Security Toilet Tissue Holder, Square, Chase Mount
Recessed toilet tissue holder that is fabricated of 14 gauge type 304 stainless steel. Offers a satin finish exterior and glass blasted insterior finish. Interior depth 4-1/2" with 5" diameter is to accomodate a single standard roll of tissue tissue paper. Mounting flange is 7" (179mm) Square and includes Mounting Hardware. Designed in mind for Behavioral Health and Detention Centers.
Overall Dimensions:7″ x 7″ x 4-1/2″ (179 x 179 x 114 mm)Wall Opening: 5-1/2″ (140mm) dia.Wall Thickness Required: 4-1/2″ or lessA10-110-1 -
Fiat Partition Slide Bolt Latch
The Fiat Toilet Partition Slide Bolt Latch is constructed of Zamac die cast metal and then chrome plated and polished. Latch base is 4" high with 2-3/4" hole spacing. Latch bolt is 3-3/16" long by 3/4" wide by 3/16" thick. The latch bolt clearance is 9/16" from the back of the base to the under side of the latch bolt and projects out 15/16". The latch projects out 1-9/16" from the face of the door when installed. Also known as a Bathroom Stall Surface Mounted Slide Bolt Latch and Toilet Partition Locks. Manufacture part # 5020. Shipped with mounting screws.
9F0302 -
ASI Recessed Security Toilet Tissue Holder, Square, Front Mount
Recessed toilet tissue holder that is fabricated of 14 gauge type 304 stainless steel. Offers a satin finish exterior and glass blasted insterior finish. Interior diameter is 5" with 4-1/2" depth to accomodate a single standard roll of tissue tissue paper. Mounting flange is 7-1/8" (181mm) Square and features front mounting holes. Designed in mind for Behavioral Health and Detention Centers. Mounting hardware included.
Overall Dimensions:
7-1/8″ x 7-1/8″ x 4″ (181 x 181 x 102 mm)
Wall Opening:
5-5/16″ dia. x 5″ min. depth (135 x 127 mm)
A10-110-13 -
Mills Toilet Partition Slide Bolt Latch Concealed
The Mills Toilet Partition Slide Bolt Latch Concealed is a popular latch used by them. Latch cover plates are 1-3/4" wide by 1-3/8" high. The latch switch is 1-15/32" wide. The latch bolt is 3/8" diameter. The spacing between the cover and the latch 1-1-32". They are constructed of Zamac die cast metal that is then chrome plated and polished. This is a one of a kind latch. Also known as a Bathroom Stall Concealed Latch. Manufacture part # 4230, HDWT T290.
90T290 -
Stainless Steel Partition Slide Bolt Latch 3/8" Bar To Door, 2-3/4" Screws
The Partition Slide Bolt Latch Stainless Steel 3/8" Bar To Door, 2-3/4" Screws is constructed of cast stainless steel. The latch base is 4" high with 2-3/4" hole spacing. Latch bolt is 3-3/4" long by 3/4" wide by 3/16" thick. The latch bolt clearance is 3/8" from the back of the base to the under side of the latch bolt and projects out 15/16". The latch projects out 1-9/16" from the face of the door when installed. Also known as a Bathroom Stall Surface Mounted Slide Bolt Latch and Toilet Partition Locks. Manufacture part # 5033. Shipped with mounting security screws.
9A5033 -
Partition Aluminum Slide Bolt Latch 3-1/2" Screws
The Partition Aluminum Slide Bolt Latch 3-1/2" Screws is constructed of extruded aluminum that is then anodized. Base is 4-1/2" by 2" by 1/8" thick and projects out 1-5/8". Latch bolt is 1" wide by 3-1/8" long by 1/4" thick, and has a 1" throw. This Bathroom Stall Latch is usually used on Solid Plastic (HDPE) Toilet Partition's. Manufactures part # are 5054, and 650-8543. Also known as Toilet Partition Locks. Shipped with mounting hardware.
9A0102 -
Partition Slide Bolt Latch Chrome Plated
The Partition Slide Bolt Latch Chrome Plated is constructed of Zamac die cast metal that is then chrome plated and polished. The latch measures 1-1/2" Wide X 3-1/4" High, and 2-3/4" Between Screws. We find this latch used on Accurate Partition Corp and Global Partition corp restroom stalls. Also known as a Surface Mounted Bathroom Stall Slide Latch and Toilet Partition Locks. Known as 40-8512899. Shipped with mounting screws. This latch is Ada approved.
9A2899 -
Metpar Toilet Partition Slide Bolt Latch
The Metpar Toilet Partition Slide Bolt Latch is constructed of Zamac die cast metal and then chrome plated. Latch base is 4" high with 2-3/4" hole spacing. Latch bolt is 3-3/16" long by 3/4" wide by 3/16" thick. The latch bolt clearance is 9/16" from the back of the base to the under side of the latch bolt and projects out 15/16". The latch projects out 1-9/16" from the face of the door when installed. Also known as a Bathroom Stall Surface Mounted Slide Bolt Latch. Manufacture part # 5020. Shipped with mounting screws.
9CP100 -
General Toilet Partitions Slide Bolt Latch
The General Toilet Partitions Slide Bolt Latch is constructed of Zamac die cast metal that is chrome plated and polished. Latch base is 4" high with 2-3/4" hole spacing. Latch bolt is 3-3/16" long by 3/4" wide by 3/16" thick. The latch bolt clearance is 9/16" from the back of the base to the under side of the latch bolt and projects out 15/16". The latch projects out 1-9/16" from the face of the door when installed. Also known as a Bathroom Stall Surface Mounted Slide Bolt Latch. Manufacture part # 5020. Shipped with mounting screws.
92000P -
Global Partitions Slide Bolt Latch
The Global Toilet Partitions Slide Bolt Latch is made of zamac die cast metal and then chrome plated and brought to a polished finish. This latch was used by Accurate Partition Corp and Global Partitions. Latch base is 4-1/2" high with 3-1/2" hole spacing. Latch bolt is 3-3/32" long by 1" wide by 3/16" thick. The latch bolt clearance is 9/16" from the back of the base to the under side of the latch bolt and projects out 15/16". The latch projects out 1-9/16" from the face of the door when installed. Also known as a Bathroom Stall Surface Mounted Slide Bolt Latch and Toilet Partition Locks. Manufacture part # 5050 and also the same as 9G0136. This latch ships with the mounting screws.
9G0136 -
Partition Slide Bolt Latch 3/8" Bar To Door Clearance
The Toilet Partition Slide Bolt Latch 3/8" Bar To Door Clearance is just like every other slide bolt, except it has an offset bolt. Latch base is 4" high with 2-3/4" hole spacing. Latch bolt is 3-3/4" long by 3/4" wide by 3/16" thick. The latch bolt clearance is 3/8" from the back of the base to the underside of the latch bolt and projects out 15/16". The latch projects out 1-9/16" from the face of the door when installed. They are constructed of Zamac die cast metal that is then chrome plated and polished. Also known as a Bathroom Stall Surface Mounted Slide Bolt Latch and Toilet Partition Locks. Manufacturer part # 5030. Shipped with mounting screws.
90T160 -
American Sanitary Toilet Partition Slide Bolt Latch
The American Sanitary Toilet Partition Slide Bolt Latch is constructed of Zamac die cast metal that is chrome plated and polished. Latch base is 4" high with 2-3/4" hole spacing. Latch bolt is 3-3/16" long by 3/4" wide by 3/16" thick. The latch bolt clearance is 9/16" from the back of the base to the under side of the latch bolt and projects out 15/16". The latch projects out 1-9/16" from the face of the door when installed. Also known as a Bathroom Stall Surface Mounted Slide Bolt Latch. Manufacture part # 5020. Shipped with mounting screws.
9AM500 -
Accurate Toilet Partition Slide Bolt Latch
The Accurate Toilet Partition Slide Bolt Latch is made of zamac die cast metal and then chrome plated and brought to a polished finish. This latch was used by Accurate Partition Corp and Global Partitions. Latch base is 4-1/2" high with 3-1/2" hole spacing. Latch bolt is 3-3/32" long by 1" wide by 3/16" thick. The latch bolt clearance is 9/16" from the back of the base to the under side of the latch bolt and projects out 15/16". The latch projects out 1-9/16" from the face of the door when installed. Also known as a Bathroom Stall Surface Mounted Slide Bolt Latch and Toilet Partition Locks. Manufacture part # 5050 and also the same as 9G0136. This latch ships with the mounting screws.
9HAP20 -
Partition Slide Bolt Latch W/Indicator Cast Stainless Steel
The Partition Slide Bolt Latch with Indicator is constructed of Cast Stainless Steel. It is designed for 3/4" or 1" thick doors, and has a screw spacing of 2-3/4" on center. We find this latch on Global Partition Corp and Global Partition Corp restroom stalls. The manufacturer part number is 8563009. This latch is Ada approved. There is no exact replacement available.
Sorry no longer available, see links for options
https://www.partitionsandstalls.com/partition-hardware/latches/chrome-plated.html
https://www.partitionsandstalls.com/partition-hardware/latches/cast-stamped-stainless-steel.html
9G2000
